Graphene IR plate

Graphene IR plate is widely used for heating elements in kitchen electric/small household appliances. It provides high-performance, extremely lightweight, innovative kitchen electric/small home appliance heating elements.

Request a quote

PRODUCT CHARACTERISTICS

Uniform surface heating and temperature uniformity increased by 80%.

The heating rate and thermal efficiency increased by 20%.

Unique far infrared penetrating heating improves the user experience and food taste.

PRODUCT SPECIFICATION

Rated voltage	100-400V
Dimensions(mm)	50-400mm(L&W rectangle), 50-250mm(Φ circular)
Max power density	2W/cm2
Typical operating temperature	350-500℃
lnfrared wavelength	2.5-25um
Lifetime	20000h
Application	Domestic appliances and industry applications

The technological breakthrough of graphene electric heating layer:

Suitable for dry burning (500℃) environment of small household appliances, stable operation at 400℃, no attenuation of power >1000h;
Temperature deviation <±2.5%, uniform heating, good consistency;
The degree of material process completion is high and meets the cost requirements of household appliances.

Thermal insulation layer technology breakthrough:

Inorganic component, limit temperature resistance up to 800℃;
Excellent insulation, breakdown voltage >5000V at 75um thickness;
The insulation performance has no attenuation at 350℃ for 720h;
High-temperature insulation leakage current is only 10mA at 350℃ and 3000V.
